Enhanced TDS
Knowde-enriched technical product data sheet
Identification & Functionality
- Additives Included
- Chemical Family
- Polymer Name
- Technologies
- Product Families
Features & Benefits
- Labeling Claims
- Materials Features
- Specific Features
- Food-contact
- General purpose
- Reduced volatile content
Applications & Uses
- Markets
- Applications
- Plastics & Elastomers End Uses
- Plastics & Elastomers Processing Methods
- Applications
- Anti-Slip Coating
- Baby Care
- Battery
- Cable Accessories
- Connector Seals
- Dairy Applications
- Flame & Heat Protection
- General Automotive Parts
- Household Applications
- Industrial Textiles
- Molded Parts
- Molded Seals (LSR)
- Sanitary
- Textiles for Protective Clothing
- Vibration Dampers
- Application Details
These grades are particularly suitable for the economical production of large series of injection-molded articles. Parts made from ELASTOSIL® LR 3003/20 TR A/B can be used for technical applications. These articles are also suitable for use in conjunction with foodstuffs. Postcured parts can be used for food contact applications and are suitable for use under the Recommendation "XV. Silicones" of the BfR and FDA § 177.2600 under observance of any given limitations on extractable and volatile substances.
Processing
The A and B components are delivered ready to use in 20 kg pail and 200 kg drum kits. With adequate metering equipment, they can be pumped directly from the original containers into the injection molding machine and mixed by a static mixer. The mixing ratio is 1 : 1. At room temperature, mixtures of A and B components have a pot life of at least three days.
Properties
- Physical Form
- Cured Properties
Value Units Test Method / Conditions Compression Set (at 22 hours, 175°C) 17 % DIN ISO 815-1 type B method A Density 1.09 g/cm³ DIN EN ISO 1183-1 A Dielectric Strength (1mm sheet) 23 kV/mm IEC 60243-1 Dissipation Factor (tan δ, at 50Hz) 2 x 10⁻⁴ - IEC 62631-2-1 Elongation (at break) 870 % ISO 37 Type 1 Permittivity (at 50Hz) 2.8 - IEC 62631-2-1 Rebound Resilience 45 % ISO 4662 Shore Hardness A 22 - DIN ISO 48-4 Tear Strength 24 N/mm ASTM D 624 B Tensile Strength 8.3 N/mm² ISO 37 Type 1 Volume Resistivity 5 x 10¹⁵ Ohm-cm IEC 62631-3-1 - Uncured Properties
Value Units Test Method / Conditions Dynamic Viscosity (Shear rate 1 s⁻¹) 370000 mPa·s DIN EN ISO 3219 Dynamic Viscosity (Shear rate 10 s⁻¹) 210000 mPa·s DIN EN ISO 3219 - Properties
Narrow Shore hardness range from 18 to 24 Shore A (21 ± 3 Shore A). This product can be used within a temperature range of - 55°C to + 210°C. The addition of heat stabilizers at service temperatures of more than 180°C is recommended.
- Note
Cure conditions : 5 min / 165°C in press, post-cured 4h / 200°C.
Regulatory & Compliance
Packaging & Availability
- Country Availability
- Packaging Type
- Regional Availability
- Packaging Information
This product is available in 20 kg pail and 200 kg drum kits.
Storage & Handling
- Storage Information
Once opened, containers should always be resealed after use to prevent the platinum catalyst from being poisoned by amines, sulfur or phosphorus compounds.
