Enhanced TDS
Knowde-enriched technical product data sheet
Identification & Functionality
- Chemical Family
- Polymer Name
- Composite Materials Functions
- Technologies
- Product Families
Features & Benefits
- Materials Features
Applications & Uses
- Markets
- Applications
- Composites End Use
- Composites Processing Methods
- Formulation Guidelines
- Crystic 2-8500PA should be allowed to attain workshop temperature (18°C - 20°C) before use. Stir well by hand, or with a low shear mixer to avoid aeration, and then allow to stand to regain thixotropy.
- Crystic 2 - 8500PA requires only the addition of catalyst to start the curing reaction. The recommended catalyst is Catalyst M (or Butanox M50), which should be added at 1% into the resin.
- The catalyst should be thoroughly incorporated into the resin with a low shear mechanical stirrer where possible.
- Pot Life
Temperature Pot Life Pot life in minutes at 15ºC 42
Pot life in minutes at 20ºC 22 Pot life in minutes at 25ºC 17 The resin, mould and workshop should be at, or above, 15°C before curing is carried out.
- Application
Crystic 2-8500PA is designed for hand laminating and would normally be used with chopped strand mat. Higher specification reinforcements are not recommended.
Additives
- The addition of filler or pigments can adversely affect the hardening of the resin. Users should evaluate the effect of any potential additives before use.
Post curing
- Satisfactory laminates for most non-critical applications can be made with Crystic 2-8500PA by curing at workshop temperature (20°C).
Properties
- Color (Properties)
- Appearance
- Greenish blue
- Typical Liquid Resin Properties
Value Units Test Method / Conditions Volatile Content 43 % - Specific Gravity (at 25°C) 1.12 - - Geltime (at 25°C using 1% Catalyst M (or Butanox M50)) 17 minutes - - Cured Properties
Value Units Test Method / Conditions Barcol Hardness (Model GYZJ 934-1)* 42 - - Deflection Temperature Under Load (1.80 MPa)*† 67 ºC - Water Absorption (24 hours at 23°C)* 15 mg - Tensile Strength* 50 MPa - Tensile Modulus* 3800 MPa - Elongation (at Break)* 1.5 % - - Laminate properties
Value Units Test Method / Conditions Tensile Strength** 98 MPa - Tensile Modulus** 7600 MPa - Elongation (at Break)** 1.7 % - Flexural Strength** 190 MPa - Flexural Modulus** 7400 MPa - - Note
* Curing schedule - 24 hours at 20°C, 3 hours at 80°C
† Curing schedule - 24 hours at 20°C, 5 hours at 80°C, 3 hours at 120°C
** Made with 4 layers 450g/m2 PB CSM Curing schedule - 24 hours at 20°C, 16 hours at 40°C
Packaging & Availability
- Packaging Type
- Packaging Information
Crystic 2-8500PA is supplied in 25kg and 225kg containers.
Storage & Handling
- Shelf Life
- 6 Months
- Storage Condition
Temperature Pot Life Pot life in minutes at 15ºC 42
Pot life in minutes at 20ºC 22 Pot life in minutes at 25ºC 17 The resin, mold and workshop should be at, or above, 15°C before curing is carried out.
