Enhanced TDS
Knowde-enriched technical product data sheet
Identification & Functionality
- Additives Included
- Chemical Family
- Polymer Name
- Plastics & Elastomers Functions
- Technologies
- Product Families
Features & Benefits
Applications & Uses
- Markets
- Applications
- Plastics & Elastomers End Uses
- Plastics & Elastomers Processing Methods
- End Uses
Fluon CD127E are high extrusion pressure polymers which have been designed for paste extrusion at low to medium reduction ratio into tubes including pipe liners. Their excellent stability makes them ideally suited to the long sintering cycles needed when making thick section tubes for pipe liners.
CD123E has higher extrusion pressure and may be used at reduction ratios from 15 to 300:1. CD127E may be used at higher reduction ratios than CD123E. CD123E is also suited to the manufacture of electrical tapes of good tensile strength and good thermal stability.
Properties
- Physical Form
- Typical Properties
Value Units Test Method / Conditions Bulk Density 545 kg / m³ FTM 126 Extrusion Pressure (at Reduction Ratio 400:1, 1.59 mm Die) 35 Mpa FTM 19a Mean Particle Size 475 microns FTM 125 Moisture (Weight loss) max. 0.05 % FTM 140 Moisture Content (Desiccant Pack Weight Increase 3 Days After Packing) max. 6 g FTM 121 Reduction Ratio Range 25 - 400 - - SSG 2.16 - FTM 128
Regulatory & Compliance
- Disposal
Waste polymer should be disposed of by landfill in accordance with any local regulations for the disposal of products of low toxicity or may be incinerated under approved controlled conditions.
- Food Contact Approval
Information on food contact approval is available from AGC Chemicals Europe, Ltd sales office.
Technical Details & Test Data
- Processing
Fluon CD127E can be processed by paste extrusion of a lubricated mix followed by drying and sintering. Further information on these techniques may be found in Technical Service Note F3/4/5, "The processing of Fluon PTFE coagulated dispersion powders".
This information sheet contains typical property data which should not be used for specification purposes.
Packaging & Availability
- Packaging Type
- Packaging
Fluon CD127E are packed in plastic kegs with plastic lids containing 25 kg.
Storage & Handling
- Storage and Handling
Fluon CD123E should be stored in clean dry conditions at 15ºC - 18ºC to ensure they do not become compacted and remain easy to sieve.
The lubricated mixes of powder should be stored at 25ºC for 24 hours before use in air tight containers to ensure that the lubricant is evenly distributed and that the powder will preform and extrude uniformly.
